Hioki DT4221 Digital Multimeter, 40Hz to 1kHz VAC

Availability: Regular Price

Hioki DT4221 Offers

Great for electrical work, this Hioki DT4221 Digital Multimeter features a pocket-sized design for simple portability. The test leads can be wrapped around the back for easy storage. The DMM is capable of measuring a 40 Hz to 1 kHz VAC bandwidth.

Features

• Designed for testing electrical wires
• Pocket-size design allows for easy portability
• Measures bandwidths from 40 Hz to 1 kHz VAC with ±0.5% VDC accuracy
• Impact-resistant construction withstands a drop from 3.28' (1 m)
• Wrap the test leads around the back for convenient storage
• Low-pass filter
• Operates on a single AAA battery

Hioki DT4221 Specifications

Specifications

AC Voltage	6 to 600 V
DC Voltage	600 mV to 600 V
Frequency	99.99 Hz to 9.999 kHz with ±0.1% of reading ±2 digits
Voltage Detection	80 V to 600 VAC
Capacitance	1 nF to 100 mF in 9 ranges with ±1% of reading ±5 digits
Power Supply	AAA Battery
Display	4-digit LCD, 6,000 digits maximum, bar graph
Display Refresh Rates	5 times/second
Diode Test	2.5 V or less (open terminal voltage), 0.5 mA or less (testing current), 0.15 to 1.5 V (threshold of forward voltage)
Additional Functions	Filter, display value hold, relative display, auto-power save
Dimensions	1.5 x 2.83 x 5.87" (38 x 72 x 149 mm)
Weight	6.7 oz (190 g)
Manufacturer Warranty	3-Year limited

What's included with the Hioki DT4221

• Digital Multimeter
• DT4911 Test Lead
• Holster
• AAA Battery
• Instruction Manual
