Mitutoyo 7223A ABSOLUTE Mechanical Dial Depth Gauge with extension rods, 0 to 10 mm
SKU: 7223A
Availability: Regular Price Mitutoyo 7223A Offers Gather depth data with the Mitutoyo 7223 ABSOLUTE Mechanical Dial Depth Gauge with extension rods. It’s easy to use and built to last. Simply probe target depths and view your readings on its clear dial face. Features Back plunger type dial indicator allows you to view readings from an upward facing direction Carbide-tipped ball contact point produces precise readings Quick and easy to use 5-pie
Availability: Regular Price
Mitutoyo 7223A Offers
Gather depth data with the Mitutoyo 7223 ABSOLUTE Mechanical Dial Depth Gauge with extension rods. It's easy to use and built to last. Simply probe target depths and view your readings on its clear dial face.
Features
- Back plunger type dial indicator allows you to view readings from an upward facing direction
- Carbide-tipped ball contact point produces precise readings
- Quick and easy to use
- 5-piece extension rod set included
Mitutoyo 7223A Specifications
Specifications
| Measurement Range | 0 to 10 mm |
| Display Type | Dial |
| Accuracy | 0.015 mm |
| Resolution | 0.01 mm |
| Stroke | 10 mm |
| Product Type | Depth gauge |
| Base Flatness | 5 μm |
| Measuring Force (N) | 1.4 N |
What's included with the Mitutoyo 7223A
- ABSOLUTE Mechanical Dial Depth Gauge
- 5 x Extension Rods (10, 20, 30, 30, 100 mm)
Mitutoyo 7223A ABSOLUTE Mechanical Dial Depth Gauge with extension rods, 0 to 10 mm. Great savings PLUS Free Shipping when you buy now from EquipTestPro.com.
